Lapp High Temperature Wire 0.75 mm² CSA, Black 100m Reel

Product Details

Olflex® Heat 105 PVC Vinyl Cable

Heat resistant PVC cables with protective conductor GN/YE
Suitable for the connection of motors, transformers, machines, appliances, switch cabinets and other installations with increased ambient temperature
At room temperature resistant to a multitude of oils and chemical media
Flame retardant in accordance with IEC 60 332.1
Fine wire strands of plain copper, Class 5
Cores twisted in layers
Outer Sheath of heat resistant PVC, black
Based on VDE regulation VDE 0281 or 0250
Specific insulation resistance >10GΩ x cm
Minimum bending radius for flexible applications 15 x cable dia. for static use 4 x cable dia.
Rated Voltage 300/500V
Conductor stranding fine wire in accordance with VDE 0295 CI.5/IEC 60228 CI.5

Specifications
